Air Curtains

F Door-Mounted Air Curtain Series

F Door-Mounted Air Curtain Series is a air curtains option for commercial doorways, compact entries, standard-height openings and similar projects.

Start here

Start here when the project needs air curtains for commercial doorways or compact entries. Confirm dimensions, voltage, access, controls, and current model documents before selecting an exact model.

Seriesproduct overview Air Curtainsproduct family Documentsmodel documents
  • Commercial doorways
  • Compact entries
  • Standard-height openings

Series options

Compare F Door-Mounted Air Curtain Series options

Review photos, key specs, typical uses, and document needs before requesting current model documents.

F Door-Mounted Air Curtain equipment view

F Series

F Door-Mounted Air Curtain

F series door-mounted air curtain for compact commercial openings with width options from 900 mm to 2000 mm and a 2.0-3.0 m mounting-height range.

F Door-Mounted Air Curtain should be reviewed around commercial doorways, standard-height entrances, compact entry protection, mounting conditions, electrical service, controls, and access for installation or service.

Use the visible product photos and model reference image to start the comparison, then confirm release documents before quoting, submittal, certification language, or final project use.

Key specs
Airflow Cross-flow fan; confirm exact airflow table Model review Voltage Confirm the US voltage option Model review Mounting Door mounted; mounting height 2.0-3.0 m Project input
Typical uses
  • Commercial doorways
  • Standard-height entrances
  • Compact entry protection
Build notes
  • 900-2000 mm width range
  • Full metal arc body with powder-coated finish
  • Copper motor and cross-flow fan details
  • Mounting-height range is 2.0-3.0 m
Check current model documents before quote or submittal use. Model data

Technical parameters

F Door-Mounted Air Curtain technical parameters

The first model table shows how to read available values before final confirmation on the exact model page.

Spec field Selection value Use boundary
Model number F Series Model identifier
Airflow Cross-flow fan; confirm exact airflow table Confirm by model
Voltage and phase Confirm the US voltage option Confirm by model
Dimensions 900-2000 mm width range; confirm inch dimensions Confirm by model
Weight Confirm shipping and installed weight Confirm by model
Mounting type Door mounted; mounting height 2.0-3.0 m Project input
Warranty Confirm warranty terms by product and sales channel Confirm by model

Factory reference

Factory model reference

Equipment photos

Equipment views that change selection

Use the photos to confirm the visible form factor, access side, mounting details, and service points before reading the longer selection notes.

F Door-Mounted Air Curtain Series equipment detail 1
Product viewReview the form factor here; confirm performance and documents separately.

Applications

Applications

For submittal documents or current model documents, prepare door dimensions, mounting height, voltage, heated or unheated preference, controls, quantity, and any certification or document requirement by exact model.

Typical uses

Review doorway width, clear opening height, traffic pattern, wind exposure, and whether the entrance is retail, restaurant, cold-room, or service-door use. Treat a restaurant entrance air curtain with frequent door traffic as a separate review from a cold-room or low-traffic interior opening.

Selection boundary

Review this series when the project needs a surface-mounted door air curtain. Move to another series when the opening needs a different motor class, heated construction, recessed mounting, cold-storage duty, or wider industrial coverage.

Installation review

Check header clearance, bracket position, electrical access, door sensor expectations, and discharge direction before treating the model as ready for ordering. Photos of the doorway usually improve the first review.

Parameter reading

Read airflow, velocity, sound, width, voltage, and control notes together. A door-width match alone is not enough when comfort, insect control, heating, or cold-room separation is part of the decision.

Sizing Inputs

Open doors create comfort complaints, insect entry, dust movement, and temperature swings that need doorway-specific review.

Start with the visible model cards above, then collect the few site conditions that change equipment fit before requesting final model documents.

  • Start with finished door width, finished door height, and mounting height.
  • Confirm whether the opening is indoor-to-outdoor, conditioned-to-unconditioned, or cold-room service.
  • Review voltage, heating preference, control method, and available mounting space before model review.
Door widthMounting heightHeated or unheatedVoltageAir velocity or airflow dataSound rating where available
