Air Curtains

X5 Centrifugal Air Curtain Series

X5 Centrifugal Air Curtain Series is a air curtains option for taller doors, commercial entries, high-airflow review and similar projects.

Start here

Start here when the project needs air curtains for taller doors or commercial entries. Confirm dimensions, voltage, access, controls, and current model documents before selecting an exact model.

Seriesproduct overview Air Curtainsproduct family Documentsmodel documents
Typical uses 3 checks Key inputs Door width / Mounting height / Heated or unheated / Voltage Product documents 1 available Request model documents Model review
  • Taller doors
  • Commercial entries
  • High-airflow review
Request model documents

Series options

Compare X5 Centrifugal Air Curtain Series options

Review photos, key specs, typical uses, and document needs before requesting current model documents.

X5 Centrifugal Air Curtain equipment view

X5 Series

X5 Centrifugal Air Curtain

Centrifugal air curtain for taller commercial openings where discharge penetration, mounting height, sound, and motor data need tighter review.

X5 Centrifugal Air Curtain should be reviewed around commercial doors, taller openings, mounting conditions, electrical service, controls, and access for installation or service.

Use the visible product photos and model reference image to start the comparison, then confirm release documents before quoting, submittal, certification language, or final project use.

Key specs
Airflow Centrifugal airflow; confirm model fan data Model review Voltage Confirm the US voltage option Model review Mounting Surface-mounted unit; confirm model fit and 3.5-5 m mounting-height range Model review
Typical uses
  • Commercial doors
  • Taller openings
Build notes
  • Centrifugal turbine airflow path for higher mounting review
  • Installation notes include 3.5-5 m mounting-height range
  • Copper motor and quiet-operation details should be verified by current model documents
  • Best suited to main entrances before final door-height approval
Check current model documents before quote or submittal use. Model data

Technical parameters

X5 Centrifugal Air Curtain technical parameters

The first model table shows how to read available values before final confirmation on the exact model page.

Spec field Selection value Use boundary
Model number X5 Series Model identifier
Airflow Centrifugal airflow; confirm model fan data Confirm by model
Voltage and phase Confirm the US voltage option Confirm by model
Dimensions Confirm inch dimensions by model Confirm by model
Weight Confirm shipping and installed weight Confirm by model
Mounting type Surface-mounted unit; confirm model fit and 3.5-5 m mounting-height range Confirm by model
Warranty Confirm warranty terms by product and sales channel Confirm by model

Factory reference

Factory model reference

X5 Centrifugal Air Curtain model reference table

Factory model reference for early comparison. Confirm current model documents before submittal or release use.

Equipment photos

Equipment views that change selection

Use the photos to confirm the visible form factor, access side, mounting details, and service points before reading the longer selection notes.

X5 Centrifugal Air Curtain Series equipment detail 1
Centrifugal bodyTaller-door discussions need product airflow, sound, and mounting data.
X5 Centrifugal Air Curtain Series equipment detail 2
Front viewCheck casing depth and outlet position before selecting for a taller opening.
X5 Centrifugal Air Curtain Series equipment detail 3
Discharge detailAir pattern should be checked with model data, not inferred from the photo.

Applications

Applications

For submittal documents or current model documents, prepare door dimensions, mounting height, voltage, heated or unheated preference, controls, quantity, and any certification or document requirement by exact model.

Typical uses

Review doorway width, clear opening height, traffic pattern, wind exposure, and whether the entrance is retail, restaurant, cold-room, or service-door use. Treat a restaurant entrance air curtain with frequent door traffic as a separate review from a cold-room or low-traffic interior opening.

Selection boundary

Review this series when the project needs a surface-mounted door air curtain. Move to another series when the opening needs a different motor class, heated construction, recessed mounting, cold-storage duty, or wider industrial coverage.

Installation review

Check header clearance, bracket position, electrical access, door sensor expectations, and discharge direction before treating the model as ready for ordering. Photos of the doorway usually improve the first review.

Parameter reading

Read airflow, velocity, sound, width, voltage, and control notes together. A door-width match alone is not enough when comfort, insect control, heating, or cold-room separation is part of the decision.

Sizing Inputs

Open doors create comfort complaints, insect entry, dust movement, and temperature swings that need doorway-specific review.

Start with the visible model cards above, then collect the few site conditions that change equipment fit before requesting final model documents.

  • Start with finished door width, finished door height, and mounting height.
  • Confirm whether the opening is indoor-to-outdoor, conditioned-to-unconditioned, or cold-room service.
  • Review voltage, heating preference, control method, and available mounting space before model review.
Door widthMounting heightHeated or unheatedVoltageAir velocity or airflow dataSound rating where available
